Tray&Lid Carton

An automatic device for packing individual packages into cartons consists of a tray and a lid inserted inside. Cases are closed and glued from flat cardboard blank.


Case Packer is equipped with two automatic magazines for manual insertion of flat cardboard blank, and the magazine’s capacity is about 250 cartons.


– Magazine for manual flat carton inserting – capacity of magazine for approx. 250 cartons, changing size is made by hand wheel – time needed for changing to another format is about 30 minutes

– Machine prepared for forming Tray & Lid case with option of internal lid

– Index feeder with stations: loading, forming and closing the case

– Vacuum cups for taking flat blanks from case magazine

– Two motorized magazines, one for trays, second for hoods

– Glue applicator Nordson

– PLC controller Allen Bradley with 10” color touch screen

– SEW main drive

– 2 automatic servo tracks counting and grouping station, prepared for grouping products in vertical position – servo drive

– Easily changeable servo track belts, for different product`s thickness Servo loading arm for products group taking from servo track to ready case

– Allen Bradley servo drives

– SICK sensors

– Festo pneumatic equipment

– Full covers with safety switches


Grouping section:

– Counting and initial grouping of single product into a group according to a chosen configuration from operator’s panel – servo track

– Pushing out the single row of product by a servo drive

– Transporting the single row of product to its final station

– Final grouping of the double-row or triple-row group

– Placing a lid over a  ready double-row or triple-row group of products by a servo drive manipulator

– Servo drives Allen Bradley


Cartoning section:

– Taking a flat cardboard blank from a carton magazine by suction cups,

– Loading a ready group of products with a lid into an open case

– Closing side walls of the case – Nordson Hot Melt Glue gun

– Closing the sides of the case – Nordson Hot Melt Glue gun

– Discharging a ready case from the cartooning section

– Main AC drive
